Patented screwless clamp connection, different frame connection alternatives and clamp locking options are the features that add value to the system. Specially designed accessories ensure that the wings move smoothly.

Thanks to the fact that the frame can be completely embedded in the floor and walls, minimum aluminum profile view and maximum view are obtained, while an unobstructed transition between the inside and outside is provided.

22 mm. clamp width

20% more transparent area compared to standard sliding systems

600 Pa watertightness performance

Special carriage set design

Multi-point locking

Applicable glass thickness up to 36 mm

Frame profile depth 168 mm / Wing depth 50.2 mm

Max. wing height 3.20 m

Watertightness

9A / 600 Pa

Wind Resistance

Class C3 (1200 Pa)

Thermal Transmittance

Uw: 1.85 W/m2K / Ug: 1.1 W/m2K

Air Permeability
Class 3 (600 Pa)
